Al-Mg-Mn Alloy 3004 Aluminium Coated Sheet For Building Curtain Wall

Brand Name : JERO

Model Number : JC18

Certification : SONCAP SABER CNCA

Place of Origin : CHINA

MOQ : 7 tons

Price : 3000-3200USD/TON

Payment Terms : L/C,T/T,Western Union,MoneyGram

Supply Ability : 5,000 TONS PER MONTH

Delivery Time : 18-22 work days

Packaging Details : Seaworthy Standard Export Package

Type : Painted aluminum coil

Alloy : 3004/3105 etc

Surface : Bright

Coating : PVDF

Front coating : 15-25 microns/as your request

Back coating : 5+10 microns

Contact Now


Al-Mg-Mn Alloy 3004 Aluminium Coated Sheet For Building Curtain Wall



3004 series alloy (Al-Mn-Mg system) that undergoes surface cleaning, chemical pretreatment,

and coating application (typically with high-performance PVDF fluorocarbon or polyester paints)

followed by high-temperature curing.


Primarily used for:

  • Curtain walls

  • Roofing systems

  • Architectural decoration


Key Characteristics of 3004 Aluminum Coil

Mechanical Properties

Tensile strength: 180-240 MPa (H34 temper reaches ≥240 MPa)

Elongation: ≥8% (H34), excellent for stamping and forming

Corrosion Resistance

Mn and Mg elements enhance atmospheric/rain corrosion resistance


Formability

Excellent bendability and deep-drawing capability for complex facade shapes


Common Tempers


Temper Characteristics Typical Applications
H34 Half-hard, high strength, good formability Curtain wall panels, 3D cladding
H44 Enhanced corrosion resistance, moderate strength Coastal/high-humidity areas
O (Annealed) Soft, superior deep-drawing capability Special curved designs (less common)


Performance Advantages for Curtain Walls


♦ Lightweight

Density: 2.7g/cm³ (65% lighter than steel), reducing structural loads

♦ Aesthetic Flexibility

Custom PVDF colors (metallic, woodgrain effects) with UV resistance (ΔE<3 after 15 years)

♦ Weather Resistance

Stable performance across -40℃ to 80℃ with no cracking/deformation


Notable Project Applications



Skyscrapers: Shanghai World Financial Center (decorative elements)

Airports: Beijing Daxing Airport (curved sunshades)


Al-Mg-Mn Alloy 3004 Aluminium Coated Sheet For Building Curtain Wall



Production Range


Thickness Range 0.20 - 5.0mm
Width Range Max. 2700mm
Alloy 1050,1060, 3003, 3004,3105,5052
Paint System PE, SMP, PVDF
Color Options RAL color or as the sample



Company Advantages



Advanced Equipment



German SMS Group fully automated coating lines with ±0.01mm thickness precision,

Line Speed: 120m/min (20% faster than industry average data)

MES system enables real-time production monitoring with ≥99.3% product qualification rate

• Multi-spectral imaging detects micro-defects as small as 0.02mm² with 99.8% recognition accuracy



Technology Patents


♦ Anti-Static Color Aluminum Coil and Continuous Production System


♦ Chromium-Free Passivation Solution for Color-Coated Aluminum Coils and Preparation Method


♦ Production Process for High Solar-Reflectance Color Aluminum Coils


♦ Method for Preparing 3D Wood Grain Aluminum Coil Based on Nanoimprint Technology


♦ Low-Temperature Curing Technology
